Woven geotextile is a kind of geosynthetic material woven from high
polymer materials such as polyethylene and polypropylene. It has
very good mechanical properties, weather resistance, corrosion
resistance and water permeability. It has a compact structure and
high tensile strength, and can withstand the pressure of soil and
garbage to maintain the stability of the structure. It also has
good weather resistance and corrosion resistance, so it can be used
for a long time in various harsh environments and is not easy to
age or break. It also has very good water permeability, which can
remove excess moisture from the soil and garbage to keep the
structure dry and stable.
Key Features:
Exceptional Tensile Strength: Withstands heavy loads and high-stress conditions, making it ideal
for road construction, embankment reinforcement, and slope
stabilization.
Superior Puncture Resistance: Protects against sharp objects and abrasions, ensuring long-term
performance in demanding environments.
Excellent Filtration and Drainage: Promotes efficient water flow while preventing soil erosion,
maintaining structural integrity in drainage systems and retaining
walls.
UV and Chemical Resistance: Designed to endure harsh weather conditions and resist degradation
from chemicals, ensuring reliable performance in outdoor
applications.
Customizable Sizes and Weights: Available in various widths, lengths, and weights to meet the
specific requirements of your project.
| Product Series | Unit | Tolerance | Geotextile Mattress Fabric |
| ZXM-120-200 | ZXM250-500 | ZXM550 |
| Mass per Unit Area (Single) | g/m² | -3% | 240 | 280 | 380 |
| Tensile Strength (Longitudinal) | N/5cm | ≥ | 2500 | 3000 | 3800 |
| Elongation (Longitudinal) | % | ≤ | 30 | 30 | 30 |
| Tensile Strength (Transverse) | N/5cm | ≥ | 2300 | 2800 | 3100 |
| Elongation (Transverse) | % | ≤ | 28 | 28 | 28 |
| CBR Bursting Strength | N | ≥ | 4000 | 5000 | 6000 |
| Vertical Permeability Coefficient | cm/s | ≥ | 1.3×10⁻² | 1.5×10⁻² | 1.8×10⁻² |
| Equivalent Aperture O95 | mm | ≤ | 0.18 | 0.22 | 0.25 |
Applications:
1.Road and railway construction
2.Landfill and erosion control
3.Retaining walls and embankments
4.Drainage systems and coastal protection
5.Agriculture and landscaping projects
Choose our geotextile woven fabric for a reliable, cost-effective
solution that enhances the stability and longevity of your
construction projects. Trust in our expertise to provide the
highest quality materials for your ground stabilization needs.
Contact us today to learn more or request a sample!
