HDPE Textured Geomembrane Chemical Resistant and Temperature Adaptable for Landfill Sites

Chemical Resistant and Temperature Adaptable HDPE Textured Geomembrane for Landfill Sites

Product Introduction
Spray Coarse Geosynthetics Membrane is a special geosynthetic material. It is produced on the basis of traditional polyethylene impervious membrane production technology by updating production equipment to form a granular rough surface on the produced geomembrane. This design not only improves the frictional performance of the geomembrane surface but also has stronger tensile strength compared to the same specification smooth film.

Product Properties
1. Impermeability: Inherited the excellent impermeability characteristics of HDPE geomemofilm, effectively preventing the penetration of water and pollutants.
2 Chemical corrosion resistance: It has good chemical corrosion resistance and can resist the erosion of various chemical substances.
3. Resistance to environmental stress cracking: It can also maintain stability under harsh environmental conditions and is not easy to crack.
4. Temperature adaptability: can be used in a wide temperature range, with good heat resistance and cold resistance.
5. Surface textures: Specially designed columnar or point-like textures that provide additional friction and adhesion.
6. High coefficient of friction: The rough surface of the column points increases the coefficient of friction with soil or other covering materials, helping to prevent the geomemofilm from sliding on the slope.

Product Application
The application field of the sprayed rough geomembrane is very extensive. It can be used for landfill sites, tailings storage sites, channel seepage prevention, dike seepage prevention, and subway projects, etc. In these projects, the sprayed rough geomembrane can not only play a seepage-proof role but also enhance the membrane's anti-bearing deformation force, suitable for slope membrane surface projects that require covering soil and have a large friction coefficient.

Products series
Single textured geomembrane, double-wall textured geomembrane.

Product Specification
* Thickness(mm): 0.30mm~3.00mm
* Width: 4m~8m
* Roll length: 50m~100m (customized request accept)
PS: Customized request accept for all above.

Geomembrane Series

Textured HDPE Geomembrane For Landfill (GB/T 17643-2011(GH-2T1,GH-2T2))

Serial Number	Project	Index
Serial Number	Thickness(mm)	0.75	1.00	1.25	1.50	2.00	2.50	3.00
1	Density (g/c㎡,≥)	≥0.940
2	Textured Highth (mm)	≥0.25
3	Yield Strength (N/mm,LD/TD)	≥11	≥15	≥18	≥22	≥29	≥37	≥44
4	Breaking Strength (N/mm,LD/TD)	≥8	≥10	≥13	≥16	≥21	≥26	≥32
5	Yeild Elongation Rate (%)	≥12
6	Breaking Elongation Rate (%)	≥100
7	Rectangular Tear Strength (N)	≥93	≥125	≥160	≥190	≥250	≥315	≥375
8	Puncture Strength (N)	≥200	≥270	≥335	≥400	≥535	≥670	≥800
9	Tensile Load Stress Cracking (Notch Constant Load Tensle Method) h	≥300
10	Carbon Black Content(Rang) (%)	2.0~3.0
11	Carbon Black Dispersion	There is not more than one grade 3 in 10 data, and grade 4 and grade 5 are not allowed
12	Oxidative Induction Time (OIT)	Standard OIT (min)≥100
12	Oxidative Induction Time (OIT)	High Pressure OIT (min)≥400
13	85℃ thermal aging (Atmospheric Pressure OIT Retention After 90 Day)	≥55
14	Ultraviolet Irradiation After 1600 Hours, The OIT Retention(%)	≥50

(CJ-T234-2006)

Specification	1.00mm	1.25mm	1.50mm	2.00mm	2.50mm	3.00mm	Remark
Item
Thickness (mm)	1.00mm	1.25mm	1.50mm	2.00mm	2.50mm	3.00mm
Textured Highth (mm)	0.25
Density (g/c㎡,≥)	0.94
Tensile Properties
Yield Strength (N/mm,LD/TD)	15	18	22	29	37	44
Breaking Strength (N/mm,LD/TD)	10	13	16	21	26	32
Yeild Elongation Rate (%)	12
Breaking Elongation Rate (%)	100
Rectangular Tear Strength (N)	125	156	187	249	311	374
Puncture Strength (N)	267	333	400	534	667	800
Environmental Stress Crack Resistance (h) (A single point of incision constant tensile method)	300
Carbon Black
Carbon Black Content(Rang) (%)	2.0~3.0
Carbon Black Dispersion	Nine of 10 observation area should be grade 1 or grade 2, not more than 1 of grade3
Oxidative Induction Time (OIT)
Standard OIT (min)	100
High Pressure OIT (min)	400
85℃ Oven Ageing (Minimum Average)
90 days after baking, the standard OIT retention(%)	55
90 days after baking, the hight pressure OIT retention(%)	80
The Anti-UV Strength
Ultraviolet irradiation after 1600 hours, the standard OIT retention(%)	50
Ultraviolet irradiation after 1600 hours, the high pressure OIT retention(%)	50
-70℃ The Low Temperature Embrittlement Performance mpact	Pass
Water Vapor Penetration Coefficient g.cm (cm2.s.Pa)	≤1.0X10-13
Dimensional Stability	±2
